Yamaha TMAX TECH MAX 2020 - Page 286

5-51
GENERATOR AND STARTER CLUTCH
Removing the stator coil and oil tank
*1 When replacing the crankshaft position sensor or stator coil, replace them as a set.
*2 Apply YAMAHA bond No. 1215 (Three bond No. 1215®).
Order Job/Parts to remove Q’ty Remarks
1Oil tank 1
2 Oil tank gasket 1
3 Dowel pin 2
4 Oil strainer 1
5 Crankshaft position sensor 1
6 Stator coil 1
7 Bearing cover 1
8 Oil seal 1
9 Bearing 1
10 Bearing 1
(7)
(2)
(3)
(3)
5
10
6
3
8
9
4
7
3
1
2
*
1
*
1
New
New
LS
E
E
*
2
LT
LT
LT
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
12 N
•
m (1.2 kgf
•
m, 8.9 lb
•
ft)
T.R.
