5-69
CRANKCASE
Removing the oil seals and bearings
Order Job/Parts to remove Q’ty Remarks
Crankshaft assembly Refer to “CRANKSHAFT” on page 5-73.
Transmission Refer to “TRANSMISSION” on page 5-83.
1 Bearing retainer 2
2 Oil seal 2
3 Bearing 5
1
2
2
3
3
3
3
New
New
E
E
LS
LS
12 N
m (1.2 kgf
m, 8.9 lb
ft)
T
.
R.
LT
