ELECTRICAL COMPONENTS
21
3
4
6
5
7
8
9
10
11
12
13
14
15
16
19
20
18
2
17
1
1. Front brake light switch (for XP560E)
2. Front brake light switch (for XP560D)
3. Grip warmer (for XP560D)
4. Parking/Unlock switch
5. OFF/LOCK switch
6. Rear brake light switch (for XP560E)
7. Rear brake light switch (for XP560D)
8. Starter relay
9. Fuse box 4 (Brake light fuse) (for XP560D)/
Fuse box 5 (Cruise control fuse)
(for XP560D)
10. Fuse box 1
11. Fuse box 2
12. Fuse box 3
13. Remote control unit
14. Auxiliary DC jack
15. Windshield drive unit
16. Horn
17. Rectifier/regulator
18. Intake air pressure sensor
19. Lean angle sensor
20. Storage compartment lid lock solenoid
(for XP560D)
21. Grip cancel switch
