9-75
P00D1, P2195
• Short circuit check
Disconnect the ECU related connectors before checking.
Refer to “PARTS CONNECTED TO THE ECU” on page 9-3.
Ground short circuit check “A”
Lines short circuit check “B”
Is it in the “Recovered” condition?
YES
Go to step 8, and complete the service.
NO
Go to “Short circuit check”.
Between O
2
sensor coupler “1” and ground
red/blue–ground
black/green–ground
gray/green–ground
black/blue–ground
O
2
sensor coupler “1”
red/blue–any other coupler terminal
black/green–any other coupler terminal
gray/green–any other coupler terminal
black/blue–any other coupler terminal
ECU coupler “2”
black/green–any other coupler terminal
gray/green–any other coupler terminal
black/blue–any other coupler terminal
Fuel injection system relay coupler “3” red/blue–any other coupler terminal
R/L
B/G
Gy/G
B/L
O
B/GY/R
B
R/BG/B
Y/W
B
Y/RR/L
BB
R/LL/Y
Y/W
R
B/Y
L
Y/G
P
Lg/L
O/WW/G
Y/L
Lg/W
B/L
Br/W
Gy/G
G/L
R/G
Lg/L
W/G
W/Y
G/R
Lg/B
L/W
Lg
B/Y
L
Y/G
P
W/G
Y/L
Lg/W
B/L
Br/W
Gy/G
Lg/L
W/G
W/Y
G/RL/W
Lg
R
R/L
R/B
L/Y
R/L
B/G
Gy/G
B/L
A
B
1
1
3
2
2
*
2
**
*. XP560D
**. XP560E
Is resistance ?
YES
Go to step 5.
NO
a. Replace the wire harness.
b. Start the engine and let it idle for approximately 1 minute.
c. Check the condition of the DTC using the malfunction mode of the YDT.
To Next Page
