Yamaha TMAX TECH MAX 2020 - Page 618

9-144
P0657
EAS20601
P0657
EAS33081
TROUBLESHOOTING
Item
Fuel system voltage: incorrect voltage supplied to the injector and fuel pump.
Fail-safe system
• Able to start engine
• Able to drive vehicle
Procedure
TIP
If more than one DTC is detected at the same time, perform troubleshooting of DTC listed below first.
• P0335
1. Connection of fuel injection system relay coupler.
• Check the locking condition of the coupler.
• Disconnect the coupler and check the pins (bent or broken terminals and locking condition of the
pins).
2. Connection of ECU coupler.
• Check the locking condition of the coupler.
• Disconnect the coupler and check the pins (bent or broken terminals and locking condition of the
pins).
Is the coupler condition normal?
YES
 Go to step 2.
NO
a. Connect the coupler securely or replace the wire harness.
b. Start the engine and let it idle for approximately 5 seconds.
c. Check the condition of the DTC using the malfunction mode of the YDT.
Is it in the “Recovered” condition?
YES
 Go to step 7, and complete the service.
NO
 Go to step 2.
Is the coupler condition normal?
YES
 Go to step 3.
NO
a. Connect the coupler securely or replace the wire harness.
b. Start the engine and let it idle for approximately 5 seconds.
c. Check the condition of the DTC using the malfunction mode of the YDT.
Is it in the “Recovered” condition?
YES
 Go to step 7, and complete the service.
NO
 Go to step 3.
