Table 4.16 Auto-Tuning Input Data
Input Value
Input
Parameter
Unit
Tuning Type (T1-01)
0
Standard
1
Stationary 1
2
Line-to-Line
Resistance
3
Rotational for
V/f Control
4
Stationary 2
Motor rated power T1-02 kW YES YES YES YES YES
Motor rated voltage T1-03 Vac YES YES – YES YES
Motor rated current T1-04 A YES YES YES YES YES
Motor rated frequency T1-05 Hz YES YES – YES YES
Number of motor poles T1-06 - YES YES – YES YES
Motor rated Speed T1-07 r/min YES YES – YES YES
PG Number of pulses per
revolution
T1-08 -
YES
<1>
YES
<1>
– –
YES
<1>
Motor no-load current T1-09 A – YES – – YES
Motor rated Slip T1-10 Hz – – – – YES
Motor iron loss T1-11 W – – – YES –
<1> Input data is needed for CLV/PM only.
n
Auto-Tuning for Permanent Magnet Motors
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Automatically sets the V/f pattern and motor parameters E1-oo and E5-oo when a PM motor is used. Additionally, the
feature also sets some F1-oo parameters for speed feedback detection in Closed Loop Vector.
Table 4.17 Types of Auto-Tuning for Permanent Magnet Motors
Type Setting Application Conditions and Benefits
Control Mode
OLV/PM AOLV/PM CLV/PM
PM Motor Parameter
Settings
T2-01 = 0
• Motor does not rotate during Auto-Tuning.
• Motor test report or motor data similar to Table 4.18 are
available.
YES YES YES
PM Stationary Auto-
Tuning
T2-01 = 1
• A motor test report listing motor data is not available.
• Drive automatically calculates and sets motor parameters.
YES YES YES
PM Stationary Auto-
Tuning for Stator
Resistance
T2-01 = 2
• Useful to tune the drive when the motor data were set up
manually or by motor code and the cable is longer than 50
m.
• Should also be performed if the cable length has changed
after prior tuning.
YES YES YES
Z Pulse Offset Tuning T2-01 = 3
• PG encoder has been replaced. Calculates the Z Pulse offset.
• Requires the motor to rotate with no load or very low load.
– – YES
Table 4.18 lists the data that must be entered for Auto-Tuning. Make sure the data is available before starting Auto-Tuning.
The necessary information is usually listed on the motor nameplate or in the motor test report provided by the motor
manufacturer. Also refer to page 95 for details on the Auto-Tuning process and selection.
Table 4.18 Auto-Tuning Input Data
Input Value
Input
Parameter
Unit
Tuning Type (T2-01)
0
Parameter Calculation
1
Stationary
2
Phase
Resistance
3
Z-Pulse
Offset
Control Mode A1-02 – 5, 6, 7 5 6, 7 5 6, 7 5, 6, 7 7
Motor Code (Hex.) T2-02 –
<1> <1> <1> <2> <2> <2> <2>
Motor Type T2-03 – – – – YES YES – –
Motor rated power T2-04 kW – YES YES YES YES – –
Motor rated voltage T2-05 Vac – YES YES YES YES – –
Motor rated current T2-06 A – YES YES YES YES YES –
Motor rated frequency T2-07 Hz – YES – YES N/A – –
Number of motor poles T2-08 – – YES YES YES YES – –
Motor rated speed T2-09 r/min – – YES – YES – –
4.7 Auto-Tuning
