No. Name Setting Range Default
T2-02 PM Motor Code Selection 0000 to FFFF
Depending on A1-02
and o2-04
n
T2-03: PM Motor Type
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Selects the type of PM motor the drive will operate.
No. Name Setting Range Default
T2-03 PM Motor Type 0, 1 1
Setting 0: IPM motor
Setting 1: SPM motor
n
T2-04: PM Motor Rated Power
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Specifies the motor rated power in kilowatts.
No. Name Setting Range Default
T2-04 PM Motor Rated Power 0.00 to 650.00 kW Depending on o2-04
n
T2-05: PM Motor Rated Voltage
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Sets the motor rated voltage.
No. Name Setting Range Default
T2-05 PM Motor Rated Voltage 0.0 to 733.1 V 575.0 V
n
T2-06: PM Motor Rated Current
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Enter the motor rated current in amps.
No. Name Setting Range Default
T2-06 PM Motor Rated Current
10% to 200% of the drive
rated current.
Depending on o2-04
n
T2-07: PM Motor Base Frequency
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Enter the motor base frequency in Hz.
Note: T2-07 will be displayed when in OLV/PM.
No. Name Setting Range Default
T2-07 PM Motor Base Frequency 0.0 to 400.0 Hz 87.5 Hz
n
T2-08: Number of PM Motor Poles
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Enter the number of motor poles.
No. Name Setting Range Default
T2-08 Number of PM Motor Poles 2 to 48 6
n
T2-09: PM Motor Base Speed
Note:
PM motor control modes are not available on 600 V class drives, CIMR-Ao5oooooooo.
Enter the motor rated speed in r/min.
Note: T2-09 will be displayed when in AOLV/PM and CLV/PM.
4.7 Auto-Tuning
