YASKAWA AC Drive-A1000 User Manual

Step Display/Result
4. Enter the password “1234”.
← →
-PRMSET-
A1- 04 = 1234
(0~9999)
“0”
PRG
Enter Password
FWD
5.
Press to save the new password.
Entry Accepted
6. Drive returns to the parameter display.
← →
-PRMSET-
A1- 04 = 0
(0~9999)
“0”
PRG
Enter Password
FWD
7.
Press and scroll to A1-02.
← →
-PRMSET- PRG
Control Method
FWD
A1-02= 2 *2*
Open Loop Vector
8.
Press to display the value set to A1-02. If the first “0” blinks, parameter settings are unlocked.
← →
-PRMSET- PRG
Control Method
FWD
A1-02= 2 *2*
Open Loop Vector
9.
Use and to change the value if desired (though changing the control mode at this point is
not typically done).
← →
-PRMSET-
V/F Control
“2”
PRG
Control Method
FWD
A1-02= 0 *2*
10.
Press to save the setting, or press to return to the previous display without saving changes.
Entry Accepted
11. The display automatically returns to the parameter display.
← →
-PRMSET-
V/F Control
PRG
Control Method
FWD
A1-02= 0 *0*
Note: 1. Parameter settings can be edited after entering the correct password.
2. Performing a 2-Wire or 3-Wire initialization resets the password to “0000”.
n
A1-06: Application Preset
Several Application Presets are available to facilitate drive setup for commonly used applications. Selecting one of these
Application Presets automatically assigns functions to the input and output terminals and sets a predefined group of parameters
to values appropriate for the selected application.
In addition, the parameters most likely to be changed are assigned to the group of User Parameters, A2-01 through A2-16.
User Parameters are part of the Setup Group, which provides quicker access by eliminating the need to scroll through multiple
menus.
Refer to Application Selection on page 97 for details on parameter A1-06.
5.1 A: Initialization
124
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
