H3-14: Analog Input Terminal Enable Selection
When one of the multi-function digital input parameters is set for “Analog input enable” (H1-oo = C), the value set to H3-14
determines which analog input terminals are enabled and which terminals are disabled when the input is closed. All analog
input terminals will be enabled all of the time if H1-oo is not set to C.
No. Name Setting Range Default
H3-14 Analog Input Terminal Enable Selection 1 to 7 7
Setting 1: A1 only enabled
Setting 2: A2 only enabled
Setting 3: A1 and A2 only enabled
Setting 4: A3 only enabled
Setting 5: A1 and A3 only enabled
Setting 6: A2 and A3 only enabled
Setting 7: All analog input terminals enabled
n
Multi-Function Analog Input Terminal Settings
See Table 5.35 for information on how H3-02, H3-10, and H3-06 determine functions for terminals A1, A2, and A3.
Note: The scaling of all input functions depends on the gain and bias settings for the analog inputs. Set these to appropriate values when selecting
and adjusting analog input functions.
Table 5.35 Multi-Function Analog Input Terminal Settings
Setting Function Page
0 Frequency Bias 231
1 Frequency Gain 231
2 Auxiliary Frequency Reference 1 232
3 Auxiliary Frequency Reference 2 232
4 Output Voltage Bias 232
5 Accel/Decel Time Gain 232
6 DC Injection Braking Current 232
7 Torque Detection Level 232
8 Stall Prevention Level During Run 232
9 Output Frequency Lower Limit Level 233
B PID Feedback 233
C PID Setpoint 233
D Frequency Bias 233
Setting Function Page
E Motor Temperature (PTC Input) 233
F Through Mode 233
10 Forward Torque Limit
23311 Reverse Torque Limit
12 Regenerative Torque limit
13 Torque Limit Using Torque Reference/Speed Limit 233
14 Torque Compensation 233
15 General Torque Limit 233
16 Differential PID Feedback 233
1F Through Mode 233
30 DriveWorksEZ Analog Input 1
23331 DriveWorksEZ Analog Input 2
32 DriveWorksEZ Analog Input 3
Setting 0: Frequency Bias
The input value of an analog input set to this function will be added to the analog frequency reference value. When the frequency
reference is supplied by a different source other than the analog inputs, this function will have no effect. Use this setting also
when only one of the analog inputs is used to supply the frequency reference.
By default, analog inputs A1 and A2 are set for this function. Simultaneously using A1 and A2 increases the frequency reference
by the total of all inputs.
Example: If the analog frequency reference from analog input terminal A1 is 50% and a bias of 20% is applied by analog input
terminal A2, the resulting frequency reference will be 70% of the maximum output frequency.
Setting 1: Frequency Gain
The input value of an analog input set to this function will be multiplied with the analog frequency reference value.
Example: If the analog frequency reference from analog input terminal A1 is 80% and a gain of 50% is applied from analog
input terminal A2, the resulting frequency reference will be 40% of the maximum output frequency.
5.7 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
231
5
Parameter Details
