YASKAWA AC Drive-A1000 User Manual

No.
(Addr.
Hex)
Name Description Values Page
b5-12
(1B0)
PID Feedback Loss
Detection Selection
All Modes
0: No fault. Digital output only.
1: Fault detection. Alarm output, drive continues operation.
2: Fault detection. Fault output, drive output is shut off.
3: No fault. Digital output only. No fault detection when PID control is
disabled.
4: Fault detection. Alarm is triggered and drive continues to run. Fault
detection even when PID is disabled.
5: Fault detection. Drive output shuts off. No fault detection when PID control
is disabled.
Default: 0
Range: 0 to 5
146
b5-13
(1B1)
PID Feedback Loss
Detection Level
All Modes
Sets the PID feedback loss detection level as a percentage of the maximum
output frequency.
Default: 0%
Min.: 0
Max.: 100
146
b5-14
(1B2)
PID Feedback Loss
Detection Time
All Modes
Sets a delay time for PID feedback loss.
Default: 1.0 s
Min.: 0.0
Max.: 25.5
147
b5-15
(1B3)
PID Sleep Function Start
Level
All Modes
Sets the frequency level that triggers the sleep function.
Default: 0.0 Hz
Min.: 0.0
Max.: 400.0
147
b5-16
(1B4)
PID Sleep Delay Time
All Modes
Sets a delay time before the sleep function is triggered.
Default: 0.0 s
Min.: 0.0
Max.: 25.5
147
b5-17
(1B5)
PID Accel/Decel Time
All Modes
Sets the acceleration and deceleration time to PID setpoint.
Default: 0.0 s
Min.: 0.0
Max.: 6000.0
148
b5-18
(1DC)
PID Setpoint Selection
All Modes
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
148
b5-19
(1DD)
PID Setpoint Value
All Modes
Sets the PID target value when b5-18 = 1. Set as a percentage of the maximum
output frequency.
Default: 0.00%
Min.: 0.00
Max.: 100.00
148
b5-20
(1E2)
PID Setpoint Scaling
All Modes
0: 0.01 Hz units
1: 0.01% units (100% = max output frequency)
2: r/min (number of motor poles must entered)
3: User-set (set scaling to b5-38 and b5-39)
Default: 1
Range: 0 to 3
148
b5-34
(19F)
PID Output Lower Limit
All Modes
Sets the minimum output possible from the PID controller as a percentage of
the maximum output frequency.
Default: 0.00%
Min.: -100.00
Max.: 100.00
148
b5-35
(1A0)
PID Input Limit
All Modes
Limits the PID control input (deviation signal) as a percentage of the maximum
output frequency. Acts as a bipolar limit.
Default: 1000.0%
Min.: 0.0
Max.: 1000.0
149
b5-36
(1A1)
PID Feedback High
Detection Level
All Modes
Sets the PID feedback high detection level as a percentage of the maximum
output frequency.
Default: 100%
Min.: 0
Max.: 100
147
b5-37
(1A2)
PID Feedback High
Detection Time
All Modes
Sets the PID feedback high level detection delay time.
Default: 1.0 s
Min.: 0.0
Max.: 25.5
147
b5-38
(1FE)
PID Setpoint User Display
All Modes
Sets the display value of U5-01 and U5-04 when the maximum frequency is
output.
Default:
<1>
Min.: 1
Max.: 60000
149
b5-39
(1FF)
PID Setpoint Display Digits
All Modes
0: No decimal places
1: One decimal place
2: Two decimal places
3: Three decimal places
Default:
<1>
Range: 0 to 3
149
B.4 b: Application
388
YASKAWA ELECTRIC SIEP C710616 31B YASKAWA AC Drive – A1000 Technical Manual
