5 Operation
5.4.4 Electronic Gear
5-44
The electronic gear ratio to be set can be calculated by the following equation:
 Feedback Resolutions of Linear Scale
Calculate the electronic gear ratio with the values in the following table.
 Models for serial converter units.
 Models for heads with interpolators.
 Models for interpolators.
 When using the encoder pulse output with th
ese linear scales, the setting range of Pn281 is restricted. For details,
refer to 5.3.7 Setting Encoder Output Pulse.
 For details on this linear scale, contact
Mitutoyo.
Refer to the manuals for the linear scale and the serial converter unit for details on the scale pitch and the num-
ber of divisions on the linear scale.
Electronic gear ratio:
=
A
B
Pn210
Pn20E
=
Linear scale pitch
Travel distance per reference unit Number of divisions of serial converter unit
Linear
Type of Lin-
ear Scale
Manufacturer Linear Scale Model
Linear
Scale Pitch
[m]
Models for Serial
Converter Unit or
Models for Head with
Interpolator
Number
of Divi-
sions
Resolution
Incremental
Heidenhain
LIDA48 20
JZDP-D003-000-E
*1
256 0.078 m
JZDP-G003-000-E
*1
4096 0.0049 m
LIDA18 40
JZDP-D003-000-E
*1
256 0.156 m
JZDP-G003-000-E
*1
4096 0.0098 m
LIF48 4
JZDP-D003-000-E
*1
256 0.016 m
JZDP-G003-000-E
*1
4096 0.00098 m
Renishaw plc RGH22B 20
JZDP-D005-000-E
*1
256 0.078 m
JZDP-G005-000-E
*1
4096 0.0049 m
Magnescale Co., Ltd.
SR75-LF
*4
80 – 8192 0.0098 m
SR75-MF 80 – 1024 0.078 m
SR85-LF
*4
80 – 8192 0.0098 m
SR85-MF 80 – 1024 0.078 m
SL700
*4
, SL710
*4
,
SL720
*4
, SL730
*4
800
PL101-RY
*2
8192 0.0977 m
MJ620-T13
*3
Absolute
Mitutoyo Corporation
ST781A/ST781AL 256 – 512 0.5 m
ST782A/ST782AL 256 – 512 0.5 m
ST783/ST783AL 51.2 – 512 0.1 m
ST784/ST784AL 51.2 – 512 0.1 m
ST788A/ST788AL 51.2 – 512 0.1 m
ST789A/ST789AL
*5
25.6 – 512 0.05 m
Magnescale Co., Ltd.
SR77-LF
*4
80 – 8192 0.0098 m
SR77-MF 80 – 1024 0.078 m
SR87-LF
*4
80 – 8192 0.0098 m
SR87-MF 80 – 1024 0.078 m
Electronic gear ratio setting range: 0.001
 Electronic gear ratio (B/A)  4000
If the electronic gear ratio is outside this range, a parameter setting error 1 (A.040) will
be outpu
t.

YASKAWA SGDV SERVOPACK Specifications

General

Model	SGDV
Type	SERVOPACK
Control Modes	Position, Speed, Torque
Communication Interface	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Vibration Resistance	5.9 m/s² (0.6G) at 10-60Hz
Shock Resistance	49 m/s² (5G)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Regenerative overload, Encoder error
