6 Adjustments
6.3.2 Advanced Autotuning Procedure
6-26
 Feedforward
If Pn140 is set to the factory setting and the mode setting is changed to 2 or 3, the feedforward gain (Pn109),
speed feedforward (V-REF) input, and force feedforward (T-REF) input will be disabled.
Set Pn140.3 to 1 if model following control is used together with the speed feedforward (V-REF) input and
force feedforward
(T-REF) input from the host controller.
Refer to 6.9.2 Force Feedforward and 6.9.3 Speed Feedforward for details.
Parameter Function When Enabled Classification
Pn140
n.0
[Factory setting]
Model following control is not used together with the
speed/for
ce feedforward input.
Immediately Tuning
n.1
Model following control is used together with the
speed/force feedforward input.
• Model following control is used to make optimum feedforward settings in the SERVO-
PACK when model following control is used with the feedforward function. Therefore,
mo
del following control is not normally used together with either the speed feedfor-
ward (V-REF) input or force feedforward (T-REF) input from the host controller. How-
ever, model following control can be used with th
e speed feedforward (V-REF) input
or force feedforward (T-REF) input if required. An improper feedforward input may
result in overshooting.

YASKAWA SGDV SERVOPACK Specifications

General

Model	SGDV
Type	SERVOPACK
Control Modes	Position, Speed, Torque
Communication Interface	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Vibration Resistance	5.9 m/s² (0.6G) at 10-60Hz
Shock Resistance	49 m/s² (5G)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Regenerative overload, Encoder error
