3 Wiring and Connection
3.1.3 Using the SERVOPACK with Single-phase, 200 V Power Input
3-12
(6) How to Select Molded-case Circuit Breaker and Fuse Capacities
The following table shows the SERVOPACK’s current capacities and inrush current when using single-phase
200 V power supply. Select a molded-case circuit breaker and fuses in accordance with these specifications.
Note: To comply with the EU low voltage directive, connect a fuse to the input side as protection against accidents caused
by short-circuits. Select the fuse for the input side that are compliant with UL standards.
The table above also provides the net values of current capacity and inrush current. Select a fuse and a molded-case
circuit breaker which meet the breaking characteristics shown below.
• Main circuit, control circuit: No breaking at three times the current values shown in the table for 5 s.
• Inrush current: No breaking at the current values shown in the table for 20 ms.
Main Circuit
Power Sup-
ply
Maximum
Applicable Ser-
vomotor
Capacity
[kW]
SERVO-
PACK Model
SGDV-
Power Supply
Capacity per
SERVOPACK
[kVA]
Current Capacity Inrush Current
Main Circuit
[Arms]
Control Cir-
cuit
[Arms]
Main Circuit
[A0-p]
Control Cir-
cuit
[A0
-p]
Single-phase,
200 V
0.05 R70A 0.2 2
0.2 33
70
0.1 R90A 0.3 2
0.2 1R6A 0.7 3
0.4 2R8A 1.2 5
0.75 5R5A 1.9 9 33
To Next Page
