4.4 Basic Parameter Adjustments
154 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Adjusting the Analog Output Terminal Voltage with H4-02 and H4-03
Note: This example continues from Step 3 in the previous example. Refer to Using H4-01
to Display Monitor Contents on page 153.
Figure 4. 24
Figure 4.24 Adjusting the Monitor Output
5.
Press to display the value currently set to H4-01.
⇒
6.
Press and to set the output current (103).
⇒
7.
Save the setting by pressing .
⇒
8. The display automatically returns to the screen shown in Step 4. ⇒
9. Press the key until back at the Top Screen. ⇒
Step Display/Result
1.
Select H4-02 by pressing the and keys.
⇒
2.
Press the key to display the value currently set to H4-02:
output voltage = (10 V/100% monitor output) x output gain (H4-02)
+ output bias (H4-03)
⇒
Step Display/Result
Output Voltage
10
Gain 
V
10 V
100%0%
0 V
Monitor
Contents
100
(%)
10
Bias 
V
100
(%)
