5.7 Operator Programming Errors
5.7 Operator Programming Errors
An Operator Programming Error (oPE) occurs when an inappropriate parameter is
set or an individual parameter setting is inappropriate. The drive will not operate
until the parameter is set correctly; however, no alarm or fault outputs will occur. If
an oPE occurs, investigate the cause and refer to Table 5.11 for the appropriate
action. When oPE error is displayed, press the ENTER button to display U1-34
(oPE fault constant). This monitor will display the parameter that is causing the
oPE error.
◆ oPE Codes, Causes, and Possible Solutions
Table 5.11 oPE Codes, Causes, and Possible Solutions
LED Operator Display Error Name
oPE01
Drive Capacity Setting Fault
Drive capacity and then value set to o2-04 do not match.
Cause Possible Solutions
The drive capacity setting
(o2-04) and the actual capacity of the drive are not the
same.
Correct the value set to o2-04.
LED Operator Display Error Name
oPE02
Parameter Range Setting Error
Parameters have been set to a value outside the allowable
setting range.
Cause Possible Solutions
Parameters were set outside the possible setting range. Set parameters to the proper values.
Note: Other errors are given precedence over oPE02 when multiple errors occur at the same time.
LED Operator Display Error Name
oPE03
Multi-Function Input Selection Error
A contradictory setting is assigned to multi-function
contact inputs H1-01 through to H1-07.
• The same function is assigned to two multi-function
inputs.
• Excludes “Not used” and “External Fault.”
• Ensure all multi-function inputs are assigned to different
functions.
• Re-enter the multi-function settings to ensure this does
not occur.
The Up command was set but the Down command was
not, or vice versa.
Correctly set functions that need to be enabled in
combination with other functions.
The Up 2 command was set but the Down 2 command
was not, or vice versa.
Correctly set functions that need to be enabled in
combination with other functions.
