B.2 Parameter Table
420 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
◆ Factory Default Settings
V/f patterns when in V/f Control Mode
■ E1-03 V/f Pattern Settings for Drive Capacity: 200/400 V class
models CIMR-VBA0001 to CIMR-VBA0010; CIMR-V2A0001 to
CIMR-V2A0010; CIMR-V4A0001 to CIMR-V4A0005
■ E1-03 V/F Pattern Settings for Drive Capacity: 200/400 V class,
models CIMR-VBA0012 to CIMR-VBA0020; CIMR-V2A0012 to
CIMR-V2A0020; CIMR-V4A0007 to CIMR-V4A0011
No. U Factory Default Value
V/f OLV
E1-03 − 0 1 2 3 4 5 6 7 8 9 A B C D E F
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120 180 60.0 60.0 60.0
E1-05
<24>
<24> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
V 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
E1-08
<24>
V 18.4 18.4 18.4 18.4 40.3 57.5 40.3 57.5 21.9 27.6 21.9 27.6 18.4 18.4 18.4 18.4 12.6 15.3
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5 0.5 0.3
E1-10
<24>
V 12.0 12.0 12.0 12.0 8.0 9.0 8.0 9.0 12.0 13.0 12.0 15.0 12.0 12.0 12.0 12.0 2.3 1.5
No. U Factory Default Value
V/f OLV
E1-03 − 0 1 2 3 4 5 6 7 8 9 A B C D E F
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0 60.0 60.0
E1-05
<24>
<24> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
V 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230 230
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
E1-08
<24>
V 16.1 16.1 16.1 16.1 40.3 57.5 40.3 57.5 20.7 26.5 20.7 26.5 16.1 16.1 16.1 16.1 12.6 15.3
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5 0.5 0.3
E1-10
<24>
V 8.1 8.1 8.1 8.1 6.9 8.1 6.9 8.1 10.4 12.7 10.4 15.0 8.1 8.1 8.1 8.1 2.3 1.5

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
