YASKAWA V1000 Series Installation & Start-Up Manual

2.2 Mechanical Installation
42 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
◆ Models
■ Exterior and Mounting Dimensions
The table below matches each drive model with its appropriate drawing.
Table 2.2 Drive Models and Types
Note: For information on the amount of heat generated by the drive and appropriate
cooling methods, refer to Specifications on page 313.
Protective Design
Model CIMR-V
Page
Single-Phase
200 V Class
Three-Phase
200 V Class
Three-Phase
400 V Class
IP20/Open-Chassis
Type
BA0002A
BA0003A
2A0001A
2A0002A
2A0004A
2A0006A
– 43
BA0006A
BA0010A
BA0012A
2A0010A
2A0012A
2A0020A
4A0001A
4A0002A
4A0004A
4A0005A
4A0007A
4A0009A
4A0011A
44
BA0020A – – 46
NEMA Type 1
BA0001F
BA0002F
BA0003F
2A0001F
2A0002F
2A0004F
2A0006F
– 47
BA0006F
BA0010F
BA0012F
2A0010F
2A0012F
2A0020F
4A0001F
4A0002F
4A0004F
4A0005F
4A0007F
4A0009F
4A0011F
48
BA0020F – – 50

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
