YASKAWA V1000 Series

2.2 Mechanical Installation
46 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Table 2.7 IP20/Open-Chassis (without an EMC filter; metric)
Table 2.8 IP20/Open-Chassis (without an EMC filter; U.S. Units)
Voltage Class
Model
CIMR-V
Dimensions (mm)
W1 H1 W H D H2 D1
Weight
(kg)
Installation
Holes
Single-Phase
200 V Class
BA0020A 158 118 170 128 180 5 65 2.9 M4
Voltage Class
Model
CIMR-V
Dimensions (in)
W1 H1 W H D H2 D1
Weight
(lb.)
Installation
Holes
Single-Phase
200 V Class
BA0020A 6.22 4.65 6.69 5.04 7.09 0.20 2.56 1.3 M4
Drawing
