A.2 Power Specifications
Specifications
A
A.2 Power Specifications
Table A.2 Power Specifications 200 V Class Models
Note: 1. The Motor Capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of
the drive output amps should be equal to or greater than the motor rated current.
2. Rated motor capacity is calculated with a rated output voltage of 220 V.
Input
Phase
Drive
Duty
Default
Carrier
(kHz)
Model
Number
CIMR-V
Motor
Capacity
(kW)
Motor
Capacity
(HP)
Input
Current A
(rms)
Output
Current A
(rms)
Single-
Phase
ND 2
BA0001 0.18 0.25 2.0 1.2
BA0002 0.37 0.5 3.6 1.9
BA0003 0.55 0.75 7.3 3.3
BA0006 1.1 1.5 13.8 6.0
BA0010 2.2 3.0 20.2 9.6
BA0012 3.0 4.0 24.0 12.0
BA0020 5.5 7.5 40.0 19.6
HD —
BA0001 0.1 0.13 1.4 0.8
BA0002 0.2 0.25 2.8 1.6
BA0003 0.4 0.5 5.5 3.0
BA0006 0.75 1.0 11.0 5.0
BA0010 1.5 2.0 14.1 8.0
BA0012 2.2 3.0 20.6 11.0
BA0020 4.0 5.5 35.4 17.5
Three-
Phase
ND 2
2A0001 0.18 0.25 1.1 1.2
2A0002 0.37 0.5 1.9 1.9
2A0004 0.55 0.75 3.9 3.5
2A0006 1.1 1.5 7.3 6.0
2A0010 2.2 3.0 10.8 9.6
2A0012 3.0 4.0 13.9 12.0
2A0020 5.5 7.5 24.0 19.6
HD 10
2A0001 0.1 0.13 0.7 0.8
2A0002 0.2 0.25 1.5 1.6
Three-
Phase
HD
10
2A0004 0.4 0.5 2.9 3.0
2A0006 0.75 1.0 5.8 5.0
8
2A0010 1.5 2.0 7.5 8.0
2A0012 2.2 3.0 11.0 11.0
2A0020 4.0 5.5 18.9 17.5
