YASKAWA V1000 Series Installation & Start-Up Manual

308 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
7.5 Communication Options
7.5 Communication Options
Table 7.4 gives detailed information about the available option cards that allow
Yaskawa drives to connect to various communications networks. Consult the table
to determine which option cards may be necessary for a given environment.
Contact Yaskawa or your Yaskawa agent to order option cards.
• Option Card Selection: Refer to Yaskawa catalog for option card selection and
part numbers.
• Option Card Installation: Refer to option card manual for option card
installation instructions.
Table 7.4 Available Option Cards
Option Card Model Function Manual
CC-Link SI-C2
Allows the drive to connect to a CC-Link network. A host
controller starts and stops the drive and allows the user to
edit and reference parameter settings (output frequency,
output current, etc.) over the network.
Contact Yaskawa

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
