D.3 UL Standards
Standards Compliance
D
D.3 UL Standards
The UL/cUL mark applies to products in the United States and Canada indicates
that UL has performed product testing and evaluation and determined that their
stringent standards for product safety have been met. For a product to receive UL
certification, all components inside that product must also receive UL certification.
Figure D.2
Figure D.2 UL/cUL Mark
◆ UL Standards Compliance
This drive is tested in accordance with UL standard UL508C and complies with UL
requirements. The following conditions must be met to maintain compliance when
using this drive in combination with other equipment:
■ Installation Area
Do not install the drive to an area greater than pollution severity 2 (UL standard).
■ Main Circuit Terminal Wiring
Yaskawa recommends using UL-listed copper wires (rated at 75°C) and closed-
loop connectors or CSA-certified ring connectors sized for the selected wire gauge
to maintain proper clearances when wiring the drive. Use the correct crimp tool to
install connectors per manufacturer recommendation. Table D.2 lists a suitable
closed-loop connector manufactured by JST Corporation.
U
L
C
R
US
LISTED

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
