YASKAWA V1000 Series

D.3 UL Standards
444 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Table D.2 Closed-Loop Crimp Terminal Size (JIS C 2805)
(same for 200 V and 400 V)
Note: Use crimp insulated terminals or insulated shrink tubing for wiring connections.
Wires should have a continuous maximum allowable temperature of 75°C 600 Vac
UL-approved vinyl-sheathed insulation.
■
Low Voltage Wiring for Control Circuit Terminals
Wire low voltage wires with NEC Class 1 circuit conductors. Refer to national state
or local codes for wiring. Use a class 2 (UL regulations) power supply for the
control circuit terminal.
Wire Gauge
Terminal Screws Crimp Terminal Size
mm
2
AWG
0.5 20
M3.5 1.25 to 3.5
M4 1.25 to 4
0.75 18
M3.5 1.25 to 3.5
M4 1.25 to 4
1.25 16
M3.5 1.25 to 3.5
M4 1.25 to 4
214
M3.5 2 to 3.5
M4 2 to 4
M5 2 to 5
M6 2 to 6
M8 2 to 8
3.5/5.5 12/10
M4 5.5 to 4
M5 5.5 to 5
M6 5.5 to 6
M8 5.5 to 8
88
M5 8 to 5
M6 8 to 6
M8 8 to 8
14 6
M6 14 to 6
M8 14 to 8
22 4
M6 22 to 6
M8 22 to 8
30/38 3/2 M8 38 to 8
