YASKAWA V1000 Series Installation & Start-Up Manual

4.5 Test Run
174 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
■ Password Settings: A1-04, A1-05
The user can set a password to the drive to restrict access. The password is selected
via parameter A1-05. The selected password must be entered in parameter A1-04
to unlock parameter access (i.e. parameter setting A1-04 must match the value
programmed into A1-05). The following parameters cannot be viewed or edited
until the value programmed into A1-04 correctly matches the value as programmed
in parameter A1-05: A1-01, A1-02, A1-03, A1-06 and A2-01 through A2-33.
Note: Parameter A1-05 is hidden from view. To display A1-05, access parameter A1-04
and simultaneously depress the key and the key.
◆ Jog Operation: FJOG/RJOG
Implement Forward and Reverse Jog functions using the multi-function input
terminals (S1 to S7). Separate frequency settings for forward jog (FJOG) and
reverse jog (RJOG) cannot be set. The jog frequency reference for both forward
and reverse jog commands is set in parameter d1-17.
No.
Parameter
Name
Description
Setting
Range
Default Page
A1-01
Access
Level
Selection
Selects which parameters are accessible via the digital
operator.
0: Operation only (access to A1 and U group parameters
only)
1: User Parameters (access to a set of parameters selected
by the user)
2: Advanced Access Level (access to all parameters)
0 to 2 2 333
A2-01
to
A2-32
Preferred
Parameters
1 to 32
Parameters selected by the user are stored to the User
Parameter menu. This includes recently viewed parameters
or parameters specifically selected for quick access.
If parameter A2-33 is set to 1, recently viewed parameters
will be listed between A2-17 and A2-32. Parameters A2-01
through A2-16 must be manually selected by the user.
If A2-33 is set to 0, then recently viewed parameters will
not be saved to the User Parameter group. The entire A2
parameter group is now available for manual programming.
b1-01 to
o2-08
– 334
A2-33
Preferred
Parameter
Automatic
Selection
0: Parameters A2-01 through A2-32 are reserved for the
user to create a list of User Parameters.
1: Save history of recently viewed parameters. Recently
edited parameters will be saved to A2-17 through A2-32 for
quick access.
0,1 1 334

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
