6.5 Drive Replacement
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 287
Periodic Inspection & Maintenance
6
◆ Details on Terminal Board (TB) or Control Board (CNT)
Replacement
The drive Terminal Board retains drive parameter settings to significantly improve
the ease of drive replacement. Refer to Figure 6.13 for a flowchart to assist in
board replacement. When replacing the drive, or changing the Control Board or
Terminal Board, the following error codes may be encountered upon application of
power:
• oPE04 Drive parameter settings need to be initialized or uploaded from the TB.
• CPF06 Drive specification does not match the replaced drive.
• oPE01 Drive parameter o2-04 kVA requires setting.
Procedural Notes:
1. When replacing the drive, control board or terminal board, make sure to confirm
the kVA setting, parameter o2-04 is correct upon initial power-up.
2. Next perform an initialization, (via parameter A1-03) to obtain the desired
parameter settings.
3. In cases where a previously programmed terminal board is retained, initializing
the drive with a setting of A1-03 = 5550 may be desired to program the drive with
previously programmed settings (settings used prior to replacing the drive or
control board).

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
