YASKAWA V1000 Series Installation & Start-Up Manual

YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 325
A.4 Drive Watts Loss Data
Specifications
A
A.4 Drive Watts Loss Data
Table A.5 Watts Loss 200 V Class Single-Phase Models
Drive Duty Fc (kHz)
Model
Number
CIMR-V
Rated
Amps (A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
HD
8
BA0001 0.8 28.7 15.5 44.2
BA0002 1.6 38.8 21.9 60.7
BA0003 3.0 52.0 29.5 81.5
BA0006 5.0 80.6 43.9 124.5
BA0010 8.0 4.7 12.5 17.2
BA0012 11.0 7.2 13.7 20.9
BA0020 17.5 14.0 18.6 32.6
2
BA0001 0.8 3.0 7.1 10.1
BA0002 1.6 6.0 8.4 14.4
BA0003 3.0 12.6 10.6 23.2
BA0006 5.0 28.7 15.5 44.2
BA0010 8.0 38.8 21.9 60.7
BA0012 11.0 52.0 29.5 81.5
BA0020 17.5 80.6 43.9 124.5
ND 2
BA0001 1.2 4.7 12.5 17.2
BA0002 1.9 7.2 13.7 20.9
BA0003 3.2 14.0 18.6 32.6
BA0006 6.0 35.6 25.6 61.2
BA0010 9.6 48.6 34.5 83.1
BA0012 12.0 57.9 42.6 100.5

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
