B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 407
Parameter List
B
◆ T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal
performance
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
T1-00
Motor
Selection 1/2
Selects which set of motor parameters are used and
set during Auto-Tuning. If Motor 2 selection
(H1- = 16) is not selected, this parameter will
not be displayed.
1: 1st Motor - E1 to E2
2: 2nd Motor - E3 to E4 (this selection is not
displayed if motor 2 has not already been selected)
1, 2 1 A A − 700 —
T1-01
<41>
Auto-Tuning
Mode Selection
Selects the Auto-Tuning mode.
0: Rotational Auto-Tuning (A1-02 = 2 or 3)
2: Terminal resistance only, Stationary
Auto-Tuning (A1-02 = 0, 1, 2, or 3)
3: Auto-Tuning for the amount of On-Delay
Compensation in Open Loop Vector (OLV) control.
Only 2 and 3 are available when using V/f control,
and only 2 when using motor 2. Setting options
when using Open Loop Vector (OLV) control
include 0 and 2.
0, 2, 3
0
(“2” in
V/f
mode)
AA− 701 —
T1-02
Motor Rated
Power
Sets the motor rated power in kilowatts (kW).
Note: If motor power is given in horsepower,
power in kW can be calculated using the following
formula: kW = HP x 0.746.
0.00 to
650.00
0.40
kW
AA− 702 —
T1-03
Motor Rated
Vo l t a g e
Sets the motor rated voltage in volts (V).
0.0 to
255.5
<24>
200.0
V
<24>
AA− 703 —
T1-04
Motor Rated
Current
Sets the motor rated current in amperes (A).
10 to
200% of
drive
rated
current
<12> AA− 704 —
T1-05
Motor Base
Frequency
Sets the base frequency of the motor in Hertz (Hz).
0.0 to
400.0
60.0
Hz
AA− 705 —
T1-06
Number of
Motor Poles
Sets the number of motor poles. 2 to 48 4 A A − 706 —
T1-07
Motor Base
Speed
Sets the base speed of the motor in revolutions per
minute r/min (RPM).
0 to
24000
1750
r/min
AA− 707 —
To Next Page
