◆ d: References
Reference parameters are used to set the various frequency reference values during
operation.
<1> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for
A1-02 = 2-OLV control.
<2> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for
A1-02 = 0-V/f Control.
<3> Default setting value is dependent on parameters o2-04, Drive/kVA Selection, and A1-02, Control Method
Selection.
<6> Setting range value is dependent on parameter C1-10, Accel/Decel Time Setting Units. When C1-10 = 0 (units of
0.01 seconds), the setting range becomes 0.00 to 600.00 seconds.
<8> Default setting value is dependent on parameter C6-02, Carrier Frequency Selection.
<22> Parameter can be changed during run.
<23> Parameter cannot be changed during run when parameter A1-02 = 5-PM OLV Control.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
d1: Frequency Reference
Use d1 parameters to configure the drive frequency reference.
d1-01
<22>
Frequency
Reference 1
0.00 to
400.00
Hz
<11>
<19>
0.00
Hz
S S S 280 177
d1-02
<22>
Frequency
Reference 2
Frequency reference when multi-function input
"Multi-Step Speed Reference 1" (H1- = 3) is
on.
0.00
Hz
S S S 281 177
d1-03
<22>
Frequency
Reference 3
Frequency reference when multi-function input
"Multi-Step Speed Reference 2” (H1- = 4)
is on.
0.00
Hz
S S S 282 177
d1-04
<22>
Frequency
Reference 4
Frequency reference when multi-function input
"Multi-Step Speed Reference 1, 2"
(H1- = 3 and 4) is on.
0.00
Hz
S S S 283 177
d1-05
<22>
Frequency
Reference 5
Frequency reference when multi-function input
"Multi-Step Speed Reference 3" (H1- = 5) is
on.
0.00
Hz
A A A 284 —
d1-06
<22>
Frequency
Reference 6
Frequency reference when multi-function input
"Multi-Step Speed Reference 1, 3 "
(H1- = 3 and 5) is on.
0.00
Hz
A A A 285 —
d1-07
<22>
Frequency
Reference 7
Frequency reference when multi-function input
"Multi-Step Speed Reference 2, 3"
(H1- = 4 and 5) is on.
0.00
Hz
A A A 286 —
