YASKAWA V1000 Series Installation & Start-Up Manual

102 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
4.2 Using the Digital LED Operator
4.2 Using the Digital LED Operator
Use the LED operator to enter run and stop commands, display data, edit
parameters, as well as display fault and alarm information.
◆ Keys, Displays, and LEDs
STOP
(
Hz
)
(
Hz
)
(
A
)
(
V
)
:
:
:
:
:
:
:
:
:
:
Fref
FWD/REV Sel
Fout
lout
Mon1
Monitor
Verify
SetUpGuide
Program
Auto-Tuning
Read manual before installing.
Risk of electric shock.
Wait 1 minute for capacitor discharge after
disconnecting power supply.
To conform to requirements, make sure to
ground the supply neutral for 400V class.
WARNING
STOP
9
5
1
2
3
4 6
7
8
10
V1000
11
12
13
15
14

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
