YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 25
1.3 Drive Models and Enclosure Types
Receiving
1
1.3 Drive Models and Enclosure Types
The table in this section describes different types of drive enclosures and the drive
models that apply to them.
Table 1.1 Drive Models and Enclosure Types
Voltage Class
Max. Motor
Size (kW)
Output
Capacity A
(HD)
Enclosure Type
IP20/Open-Chassis IP20/NEMA Type 1
Single-Phase
200 V Class
0.1 0.8 CIMR-VUBA0001A CIMR-VUBA0001[B/F]
0.2 1.6 CIMR-VUBA0002A CIMR-VUBA0002[B/F]
0.4 3.0 CIMR-VUBA0003A CIMR-VUBA0003[B/F]
0.75 5.0 CIMR-VUBA0006A CIMR-VUBA0006[B/F]
1.5 8.0 CIMR-VUBA0010A CIMR-VUBA0010[B/F]
2.2 11.0 CIMR-VUBA0012A CIMR-VUBA0012[B/F]
4.0 17.5 CIMR-VUBA0020A CIMR-VUBA0020[B/F]
Three-Phase
200 V Class
0.1 0.8 CIMR-VU2A0001A CIMR-VU2A0001[B/F]
0.2 1.6 CIMR-VU2A0002A CIMR-VU2A0002[B/F]
0.4 3.0 CIMR-VU2A0004A CIMR-VU2A0004[B/F]
0.75 5.0 CIMR-VU2A0006A CIMR-VU2A0006[B/F]
1.5 8.0 CIMR-VU2A0010A CIMR-VU2A0010[B/F]
2.2 11.0 CIMR-VU2A0012A CIMR-VU2A0012[B/F]
4.0 17.5 CIMR-VU2A0020A CIMR-VU2A0020[B/F]
Three-Phase
400 V Class
0.2 1.2 CIMR-VU4A0001A CIMR-VU4A0001[B/F]
0.4 1.8 CIMR-VU4A0002A CIMR-VU4A0002[B/F]
0.75 3.4 CIMR-VU4A0004A CIMR-VU4A0004[B/F]
1.5 4.8 CIMR-VU4A0005A CIMR-VU4A0005[B/F]
2.2 5.5 CIMR-VU4A0007A CIMR-VU4A0007[B/F]
3.0 7.2 CIMR-VU4A0009A CIMR-VU4A0009[B/F]
4.0 9.2 CIMR-VU4A0011A CIMR-VU4A0011[B/F]
TERMS
TERMS
Two types of enclosures are offered for V1000 drives:
• Open-Chassis models are often placed inside a large enclosure
panel where the front of the drive is covered to prevent someone
from accidentally touching charged components.
• NEMA Type 1 models are generally mounted to an indoor wall and
not inside a large enclosure panel.
