3.8 I/O Connections
3.8 I/O Connections
◆ Sinking/Sourcing Mode Switch
Set the DIP switch S3 on the front of the drive to switch the digital input terminal
logic between sinking mode and sourcing mode; the drive is preset to sinking
mode.
Figure 3. 24
Figure 3.24 Sinking/Sourcing Mode Switch
A – DIP switch S3 C – Source
B–Sink
A
B
C
