YASKAWA V1000 Series Installation & Start-Up Manual

202 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
5.5 Fault Detection
5.5 Fault Detection
When the drive detects a fault, the digital operator displays the fault information,
the fault contact closes, and the motor coasts to a stop. However, a fault that has a
selectable stopping method will operate according to that stopping method.
Investigate the cause of a fault and refer to Table 5.9 for the appropriate action.
To restart, reset the fault with one of the following procedures:
• Set “14: Fault Reset” to a multi-function digital input (H1-01 to H1-06). Then,
close and open the input.
• Press the RESET button of the digital operator.
• Shut off the drive input power and then turn on again.
◆ Fault Displays, Causes, and Possible Solutions
Table 5.9 Detailed Fault Displays, Causes, and Possible Solutions
LED Operator Display Fault Name
bUS
Option Communication Error
• After establishing initial communication, the connection was lost.
• Only detected when the run command frequency reference is assigned to an
option card.
Cause Possible Solution
No signal is being received from the
PLC.
• Check for faulty wiring.
• Correct the wiring.
• Check for loose wiring and short circuits. Repair as needed.
The communication cable is faulty
or a short circuit exists.
A communications data error
occurred due to noise.
• Check the various options available to minimize the effects of noise.
• Take steps to counteract noise in the control circuit wiring, main circuit lines
and ground wiring.
• Ensure that other equipment such as switches or relays do not cause noise and
use surge suppressors if required.
• Use cables recommended by Yaskawa or another type of shielded line.
Ground the shield on the controller side or on the drive input power side.
• Separate all wiring for communications devices from drive input power lines.
Install a noise filter to the input side of the drive input power.
The option card is damaged.
• Replace the option card if there are no problems with the wiring and the error
continues to occur.
The option card is not properly
connected to the drive.
• The connector pins on the option card are not properly lined up with the
connector pins on the drive.
• Reinstall the option card.

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
