YASKAWA V1000 Series Installation & Start-Up Manual

38 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
2.2 Mechanical Installation
2.2 Mechanical Installation
This section describes various specifications and criteria necessary for proper
installation of the drive, outlines some installation procedures and gives detailed
information of the different drive models.
◆ Installation Environment
To help prolong the optimum performance life of the drive, install the drive in the
proper environment. The table below provides description of the appropriate
environment for the drive.
Table 2.1 Installation Environment
Environment Conditions
Installation Area Indoors
Ambient
Temperature
-10°C - +40°C (NEMA Type 1)
-10°C - +50°C (Open-Chassis Type)
When using an enclosure panel, install a cooling fan or air conditioner in the area to ensure
that the air temperature inside the enclosure does not exceed the specified levels.
Do not allow ice to develop on the drive.
Humidity 95% RH or less and free of condensation
Storage Temperature -20°C - +60°C
Surrounding Area
Install the drive in an area free from:
oil mist and dust
metal shavings, oil, water or other foreign materials
radioactive materials
combustible materials (e.g., wood)
harmful gases and liquids
excessive vibration
chlorides
direct sunlight
Altitude 1000 m or lower
Vibration
10 - 20 Hz at 9.8 m/s
2
20 - 55 Hz at 5.9 m/s
2
Orientation Install the drive vertically to maintain maximum cooling effects.

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
