1.3 Drive Models and Enclosure Types
26 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Table 1.2 Drive Models and Enclosure Types
Voltage Class
Max. Motor
Size (kW)
Output
Capacity A
(ND)
Enclosure Type
IP20/Open-Chassis IP20/NEMA Type 1
Single-Phase
200 V Class
0.18 1.2 CIMR-VUBA0001A CIMR-VUBA0001[B/F]
0.37 1.9 CIMR-VUBA0002A CIMR-VUBA0002[B/F]
0.75 3.3 CIMR-VUBA0003A CIMR-VUBA0003[B/F]
1.1 6.0 CIMR-VUBA0006A CIMR-VUBA0006[B/F]
2.2 9.6 CIMR-VUBA0010A CIMR-VUBA0010[B/F]
3.0 12.0 CIMR-VUBA0012A CIMR-VUBA0012[B/F]
5.5 19.6 CIMR-VUBA0020A CIMR-VUBA0020[B/F]
Three-Phase
200 V Class
0.18 1.2 CIMR-VU2A0001A CIMR-VU2A0001[B/F]
0.37 1.9 CIMR-VU2A0002A CIMR-VU2A0002[B/F]
0.75 3.5 CIMR-VU2A0004A CIMR-VU2A0004[B/F]
1.1 6.0 CIMR-VU2A0006A CIMR-VU2A0006[B/F]
2.2 9.6 CIMR-VU2A0010A CIMR-VU2A0010[B/F]
3.0 12.0 CIMR-VU2A0012A CIMR-VU2A0012[B/F]
5.5 19.6 CIMR-VU2A0020A CIMR-VU2A0020[B/F]
Three-Phase
400 V Class
0.37 1.2 CIMR-VU4A0001A CIMR-VU4A0001[B/F]
0.75 2.1 CIMR-VU4A0002A CIMR-VU4A0002[B/F]
1.5 4.1 CIMR-VU4A0004A CIMR-VU4A0004[B/F]
2.2 5.4 CIMR-VU4A0005A CIMR-VU4A0005[B/F]
3.0 6.9 CIMR-VU4A0007A CIMR-VU4A0007[B/F]
3.7 8.8 CIMR-VU4A0009A CIMR-VU4A0009[B/F]
5.5 11.1 CIMR-VU4A0011A CIMR-VU4A0011[B/F]

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
