YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 351
Parameter List
B
d1-08
<22>
Frequency
Reference 8
Frequency reference when multi-function input
"Multi-Step speed reference 1, 2, 3"
(H1- = 3, 4, 5) is on.
0.00 to
400.00
Hz
<11>
<19>
0.00
Hz
A A A 287 —
d1-09
<22>
Frequency
Reference 9
Frequency reference when multi-function input
"Multi-Step Speed Reference 4" (H1- = 32)
is on.
0.00
Hz
A A A 288 —
d1-10
<22>
Frequency
Reference 10
Frequency reference when multi-function input
"Multi-Step Speed Reference 1, 4"
(H1- = 3 and 32) is on.
0.00
Hz
A A A 28B —
d1-11
<22>
Frequency
Reference 11
Frequency reference when multi-function input
"Multi-Step Speed Reference 2, 4"
(H1- = 4 and 32) is on.
0.00
Hz
A A A 28C —
d1-12
<22>
Frequency
Reference 12
Frequency reference when multi-function input
"Multi-Step Speed Reference 1, 2, 4"
(H1- = 3, 4, 32) is on.
0.00
Hz
A A A 28D —
d1-13
<22>
Frequency
Reference 13
Frequency reference when multi-function input
"Multi-Step Speed Reference 3, 4"
(H1- = 5 and 32) is on.
0.00
Hz
A A A 28E —
d1-14
<22>
Frequency
Reference 14
Frequency reference when multi-function input
"Multi-Step Speed Reference 1, 3, 4"
(H1- = 3, 5, 32) is on.
0.00
Hz
AAA 28F —
d1-15
<22>
Frequency
Reference 15
Frequency reference when multi-function input
"Multi-Step Speed Reference 2, 3, 4"
(H1- = 4, 5, 32) is on.
0.00
Hz
A A A 290 —
d1-16
<22>
Frequency
Reference 16
Frequency reference when multi-function input
"Multi-Step Speed Reference 1, 2, 3, 4"
(H1- = 3, 4, 5, 32) is on.
0.00
Hz
A A A 291 —
d1-17
<22>
Jog Frequency
Reference
Frequency reference when: "Jog Frequency
Reference" is selected via multi-function input
terminals. "Jog Frequency Reference" has
priority over "Multi-Step Speed Reference 1 to
16." Parameter d1-17 is also the reference for the
JOG key on the digital operator, and the
multi-function inputs "Forward Jog" and
"Reverse Jog."
6.00
Hz
SSS 292 174
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
