YASKAWA V1000 Series Installation & Start-Up Manual

B .2 P a ra m e te r Ta b le
352 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
d2: Frequency Upper and Lower Limits
Use d2 parameters to configure the frequency reference limits.
d2-01
Frequency
Reference Upper
Limit
Sets the maximum frequency reference as a
percentage of maximum output frequency
(E1-04). If the frequency reference is above this
value, actual drive speed will be limited to this
value. This parameter applies to all frequency
reference sources.
0.0 to
110.0
100.
0%
A A A 289 —
d2-02
Frequency
Reference Lower
Limit
Sets the minimum frequency reference as a
percentage of maximum output frequency
(E1-04). If frequency reference is below this
value, actual drive speed will be set to this value.
This parameter applies to all frequency
reference sources.
0.0 to
110.0
0.0
%
A A A 28A —
d2-03
Master Speed
Reference Lower
Limit
Sets the minimum frequency reference, set as a
percentage of maximum output frequency
(E1-04). If frequency reference from analog
input(s) is below this value, actual drive speed
will be set to this value. This parameter applies
to all frequency reference sources.
0.0 to
110.0
0.0
%
A A A 293 —
d3: Jump Frequency
Use d3 parameters to configure the drive Jump Frequency settings.
d3-01 Jump Frequency 1
d3-01 to d3-04 allow programming of three
prohibited frequency reference points for
eliminating problems with resonant vibration of
the motor / machine. This feature does not
eliminate the selected frequency values, but
accelerates and decelerates the motor through
the prohibited bandwidth.
The parameters must be according to the rule;
d3-01 ≥ d3-02 ≥ d3-03.
Although the drive will not operate the motor at
the frequencies it is programmed to skip, it will
pass through the designated Jump Frequencies
normally during acceleration and deceleration.
0.0 to
400.0
0.0
Hz
A A A 294 —
d3-02 Jump Frequency 2
0.0
Hz
A A A 295 —
d3-03 Jump Frequency 3
0.0
Hz
A A A 296 —
d3-04
Jump Frequency
Width
This parameter sets the width of the dead-band
around each selected prohibited frequency
reference point.
The bandwidth becomes the designated Jump
frequency, plus or minus d3-04.
0.0 to
20.0
1.0
Hz
A A A 297 —
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
