YASKAWA V1000 Series

A.4 Drive Watts Loss Data
326 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Table A.6 Watts Loss 200 V Class Three-Phase Models
Drive Duty Fc (kHz)
Model Number
CIMR-V
Rated
Amps (A)
Heatsink
Loss (W)
Interior
Unit Loss
(W)
Total
Loss (W)
HD
8
2A0001 0.8 4.3 7.3 11.6
2A0002 1.6 7.9 8.8 16.7
2A0004 3.0 16.1 11.6 27.7
2A0006 5.0 27.4 15.9 43.3
2A0010 8.0 54.8 23.8 78.6
2A0012 11.0 70.7 29.9 100.6
2A0020 17.5 110.5 43.3 153.8
2
2A0001 0.8 3.0 7.0 10.0
2A0002 1.6 6.0 8.3 14.3
2A0004 3.0 12.6 10.6 23.2
2A0006 5.0 21.1 14.3 35.4
2A0010 8.0 38.8 19.8 58.6
2A0012 11.0 52.0 25.3 77.3
2A0020 17.5 80.6 35.8 116.4
ND 2
2A0001 1.2 4.7 11.9 16.6
2A0002 1.9 7.2 13.5 20.7
2A0004 3.5 15.1 17.7 32.8
2A0006 6.0 26.2 21.4 47.6
2A0010 9.6 48.6 30.5 79.1
2A0012 12.0 57.9 35.9 93.8
2A0020 19.6 93.3 53.0 146.3
