YASKAWA V1000 Series Installation & Start-Up Manual

A.4 Drive Watts Loss Data
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 327
Specifications
A
Table A.7 Watts Loss 400 V Class Three-Phase Models
Drive Duty Fc (kHz)
Model Number
CIMR-V
Rated
Amps
(A)
Heatsink
Loss (W)
Interior
Unit Loss
(W)
Total
Loss (W)
HD
8
4A0001 1.2 19.2 11.5 30.7
4A0002 1.8 28.9 14.8 43.7
4A0004 3.4 42.3 17.9 60.2
4A0005 4.8 70.7 26.2 96.9
4A0007 5.5 81.0 30.7 111.7
4A0009 7.2 84.6 32.9 117.5
4A0011 9.2 107.2 41.5 148.7
2
4A0001 1.2 8.2 8.6 16.8
4A0002 1.8 13.0 10.9 23.9
4A0004 3.4 21.3 12.6 33.9
4A0005 4.8 32.8 16.8 49.6
4A0007 5.5 38.2 20.0 58.2
4A0009 7.2 44.3 22.8 67.1
4A0011 9.2 57.6 29.1 86.7
ND 2
4A0001 1.2 8.2 14.4 22.6
4A0002 2.1 15.5 18.4 33.9
4A0004 4.1 26.4 21.2 47.6
4A0005 5.4 37.5 25.7 63.2
4A0007 6.9 49.7 32.4 82.1
4A0009 8.8 55.7 36.0 91.7
4A0011 11.1 71.9 51.7 123.6

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
