D.3 UL Standards
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 445
Standards Compliance
D
Table D.3 Control Circuit Terminal Power Supply
■
Drive Short-Circuit Rating
This drive has undergone the UL short-circuit test, which certifies that during a
short circuit in the power supply the current flow will not rise above 30,000 amps
maximum at 240 V for 200 V class drives and 480 V for 400 V class drives.
• The MCCB and breaker protection and fuse ratings (refer to Table D.1 ) shall be
equal to or greater than the short-circuit tolerance of the power supply being
used.
• Suitable for use on a circuit capable of delivering not more than 30,000 RMS
symmetrical amperes for 240 V in 200 V class drives (up to 480 V for 400 V
class drives) motor overload protection.
Input / Output Terminal Signal Power Supply Specifications
Digital outputs
P1*, P2*, PC*, MA, MB, MC, MP *Requires class 2 power supply.
Digital inputs S1, S2, S3, S4, S5, S6, S7, SC, H1, HC
Use the internal power supply of the
drive. Use class 2 for external power
supply.
Main frequency reference
(multi-function analog inputs)
RP, +V, A1, A2, AC
Use the internal power supply of the
drive. Use class 2 for external power
supply.

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
