YASKAWA V1000 Series Installation & Start-Up Manual

D.2 European Standards
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 441
Standards Compliance
D
■ Installing Fuses on the Input Side
Install recommended UL-approved fuses at the main power input of the drive.
Select fuses according to Table D.1:
Table D.1 Recommended Input Fuse Selection
Drive Model CIMR-V
Ferraz Time Delay/
Class RK5 Fuses
600 Vac, 200 kAIR
Fuse Ampere Rating
200 V Class Single-Phase Drives
BA0001 TRS10R 10
BA0002 TRS10R 10
BA0003 TRS20R 20
BA0006 TRS40R 40
BA0010 TRS45R 45
BA0012 TRS60R 60
BA0021 TRS90R 90
200 V Class Three-Phase Drives
2A0001 TRS5R 5
2A0002 TRS5R 5
2A0004 TRS10R 10
2A0006 TRS10R 10
2A0010 TRS30R 30
2A0012 TRS40R 40
2A0021 TRS50R 50
400 V Class Three-Phase Drives
4A0001 TRS5R 5
4A0002 TRS5R 5
4A0004 TRS20R 20
4A0005 TRS20R 20
4A0007 TRS30R 30
4A0009 TRS30R 30
4A0011 TRS40R 40

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
