A.2 Power Specifications
316 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
3. The carrier frequency default setting is 2 kHz for all ND models.
4. HD ratings have an overload of 150% for 1 minute. ND ratings have an overload of 120%
for 1 minute. Refer to Common Drive Specifications on page 317 for other drive
specifications.
Table A.3 Power Specifications 400 V Class Models
Note: 1. The Motor Capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of
the drive output amps should be equal to or greater than the motor rated current.
2. Rated motor capacity is calculated with a rated output voltage of 440 V.
3. The carrier frequency default setting is 2 kHz for all ND Duty models.
4. HD ratings have an overload of 150% for 1 minute. ND Duty ratings have an overload of
120% for 1 minute.
5. In 400 V class drives, certain restrictions apply to the maximum output frequency as
dictated by the carrier frequency and drive capacity. Contact Yaskawa for more
information. Refer to Common Drive Specifications on page 317 for other drive
specifications.
Input
Phase
Drive
Duty
Default
Carrier
(kHz)
Model
Number
CIMR-V
Motor
Capacity
(kW)
Motor
Capacity
(HP)
Input
Current A
(rms)
Output
Current A
(rms)
Three-
Phase
ND 2
4A0001 0.37 0.5 1.2 1.2
4A0002 0.75 1.0 2.1 2.1
4A0004 1.5 2.0 4.3 4.1
4A0005 2.2 3.0 5.9 5.4
4A0007 3.0 4.0 8.1 6.9
4A0009 3.7 5.0 9.4 8.8
4A0011 5.5 7.5 14.0 11.1
HD 8
4A0001 0.2 0.25 1.2 1.2
4A0002 0.4 0.5 1.8 1.8
4A0004 0.75 1.0 3.2 3.4
4A0005 1.5 2.0 4.4 4.8
4A0007 2.2 3.0 6.0 5.5
4A0009 3.0 4.0 8.2 7.2
4A0011 4.0 5.5 10.4 9.2
