YASKAWA V1000 Series

2.2 Mechanical Installation
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 45
Mechanical Installation
2
Table 2.6 IP20/Open-Chassis (without an EMC filter; U.S. Units)
Voltage Class
Model
CIMR-V
Dimensions (in)
W1 H1 W H D H2 D1
Weight
(lb.)
Installation
Holes
Single-Phase
200 V Class
BA0006A 3.78 4.65 4.25 5.04 5.41 0.20 2.28 0.7 M4
BA0010A 3.78 4.65 4.25 5.04 6.06 0.20 2.28 0.7 M4
BA0012A 5.04 4.65 5.51 5.04 6.42 0.20 2.56 1.0 M4
Three-Phase
200 V Class
2A0010A 3.78 4.65 4.25 5.04 5.08 0.20 2.28 0.6 M4
2A0012A 3.78 4.65 4.25 5.04 5.41 0.20 2.28 0.6 M4
2A0020A 5.04 4.65 5.51 5.04 5.63 0.20 2.56 1.0 M4
Three-Phase
400 V Class
4A0001A 3.78 4.65 4.25 5.04 3.19 0.20 0.39 0.4 M4
4A0002A 3.78 4.65 4.25 5.04 3.90 0.20 1.10 0.5 M4
4A0004A 3.78 4.65 4.25 5.04 5.41 0.20 2.28 0.6 M4
4A0005A 3.78 4.65 4.25 5.04 6.06 0.20 2.28 0.7 M4
4A0007A 3.78 4.65 4.25 5.04 6.06 0.20 2.28 0.7 M4
4A0009A 3.78 4.65 4.25 5.04 6.06 0.20 2.28 0.7 M4
4A0011A 5.04 4.65 5.51 5.04 5.63 0.20 2.56 1.0 M4
