2.2 Mechanical Installation
50 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
Table 2.13 IP20/NEMA Type 1 (without an EMC filter; metric)
Table 2.14 IP20/NEMA Type 1 (without an EMC filter; U.S. Units)
Voltage Class
Model
CIMR-V
Dimensions (mm)
W1 H2 W H1 D H5 D1 H H4 H3 Weight (kg)
Single-Phase
200 V Class
BA0020F 158 118 170 - 180 5 65 - 38 48 -
Voltage Class
Model
CIMR-V
Dimensions (in)
W1 H2 W H1 D H5 D1 H H4 H3 Weight (lb.)
Single-Phase
200 V Class
BA0020F 6.22 4.65 6.69 - 7.09 0.20 2.56 - 1.50 1.89 -
Drawing
