2.2 Mechanical Installation
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 49
Mechanical Installation
2
Table 2.12 IP20/NEMA Type 1 (without an EMC filter; U.S. Units)
Voltage Class
Model
CIMR-V
Dimensions (in)
W1 H2 W H1 D H5 D1 H H4 H3
Weight
(lb.)
Single-Phase
200 V Class
BA0006F 3.78 4.65 4.25 5.10 5.41 0.20 2.28 5.89 0.79 0.16 0.8
BA0010F 3.78 4.65 4.25 5.10 6.06 0.20 2.28 5.89 0.79 0.16 0.8
BA0012F 5.04 4.65 5.51 5.24 6.42 0.20 2.56 6.02 0.79 0.19 1.1
Three-Phase
200 V Class
2A0010F 3.78 4.65 4.25 5.10 5.08 0.20 2.28 5.89 0.79 0.16 0.7
2A0012F 3.78 4.65 4.25 5.10 5.41 0.20 2.28 5.89 0.79 0.16 0.7
2A0020F 5.04 4.65 5.51 5.24 5.63 0.20 2.56 6.02 0.79 0.19 1.1
Three-Phase
400 V Class
4A0001F 3.78 4.65 4.25 5.10 3.19 0.20 0.39 5.89 0.79 0.16 0.5
4A0002F 3.78 4.65 4.25 5.10 3.90 0.20 1.10 5.89 0.79 0.16 0.5
4A0004F 3.78 4.65 4.25 5.10 5.41 0.20 2.28 5.89 0.79 0.16 0.7
4A0005F 3.78 4.65 4.25 5.10 6.06 0.20 2.28 5.89 0.79 0.16 0.8
4A0007F 3.78 4.65 4.25 5.10 6.06 0.20 2.28 5.89 0.79 0.16 0.8
4A0009F 3.78 4.65 4.25 5.10 6.06 0.20 2.28 5.89 0.79 0.16 0.8
4A0011F 5.04 4.65 5.51 5.24 5.63 0.20 2.56 6.02 0.79 0.19 1.1
