B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 419
Parameter List
B
U6-17
Energy Savings
Coefficient
Calculation Value
Displays the Energy Savings coefficient
calculated in the drive when b8-01 = 2.
10 V: 100%
0.01
%
A −− 7D1
U6-18
PID Differential
Feedback
Displays the differential feedback level when
using PID with differential feedback.
10 V: 100%
0.01
%
AAA 7D2
U6-19
PID Adjusted
Feedback
Displays the final feedback level after
differential PID feedback is subtracted from
the main feedback signal.
10 V: 100%
0.01
%
AAA 7D3
U6-20
Frequency Reference
Bias (Up/Down 2)
Monitors the bias value used to adjust the
frequency reference in real time.
–
0.1
%
AAA 7D4
U6-21
Offset
Frequency
Displays the frequency added to the main
frequency reference.
Fmax / 10 V
0.1
%
AAA 7D5
U8: Custom Monitors for DriveWorksEZ
U8 parameters are reserved for DriveWorksEZ
U8-01 – Reserved for DriveWorksEZ, Monitor 1. –
0.01
%
Α A Α 1950
U8-02 – Reserved for DriveWorksEZ, Monitor 2. –
0.01
%
A A A 1951
U8-03 – Reserved for DriveWorksEZ, Monitor 3. –
0.01
%
A A A 1952
U8-04 – Reserved for DriveWorksEZ, Monitor 4. –
0.01
%
A A A 1953
U8-05 – Reserved for DriveWorksEZ, Monitor 5. –
0.01
%
A A A 1954
U8-06 – Reserved for DriveWorksEZ, Monitor 6. –
0.01
%
A A A 1955
U8-07 – Reserved for DriveWorksEZ, Monitor 7. –
0.01
%
A A A 1956
U8-08 – Reserved for DriveWorksEZ, Monitor 8. –
0.01
%
A A A 1957
U8-09 – Reserved for DriveWorksEZ, Monitor 9. –
0.01
%
A A A 1958
U8-10 – Reserved for DriveWorksEZ, Monitor 10. –
0.01
%
A A A 1959
<27> Setting units for this parameter are determined by o2-04, Drive/kVA Selection. Less than 11 kW: 2 decimal
points, 11 kW and above: 1 decimal point.
