YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
418 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
U4-23
Option Card
Reference
Displays the option card reference (Reg No.
0001H) as a 4 digit hexadecimal number.
AAA 7DF
U5: Application Monitor
Use U5 parameters to view application-specific settings.
U5-01 PID Feedback
Displays the amount of feedback during PID
control with the maximum frequency input as
100%.
10V: Max.
freq.
0.01
%
AAA 57
U5-02 PID Input (feedback)
Displays the amount of PID input as a
percentage of the max motor frequency.
0.01
%
AAA 63
U5-03 PID Output
Displays PID control output as a percentage
of the max voltage.
0.01
%
AAA 64
U5-04 PID Setpoint
Displays the setpoint for PID as a percentage
of the max current rating.
0.01
%
AAA 65
U6: Application Monitor
Use U6 parameters to display drive control information.
U6-01
Torque Reference
(Internal)
Displays the internal torque reference in
Open Loop Vector (OLV) control.
10 V: Motor
rated torque
0.1
%
− A − 48
U6-02
Motor Secondary
Current (Iq)
Displays the value of the motor secondary
current (Iq).
10 V: Motor
rated
secondary
current
0.1
%
AAA 51
U6-03
Motor Excitation
Current (ld)
Displays the value calculated for the motor
excitation current (Id) as a percentage of the
motor rated secondary current (Iq).
10 V: Motor
rated
secondary
current
0.1
%
− AA 52
U6-04
Output of speed
control (ASR)
(for Simple V/f PG)
0.1% A −− 55
U6-05
Output voltage
reference (Vq)
Output voltage reference (Vq).
(q-axis)
0.1 Vac − AA 59
U6-06
Output Voltage
Reference (Vd)
Output voltage reference (Vd).
(d-axis)
0.1 Vac
10 V: 200 V
(400 V)
0.1
VA C
− AA 5A
U6-07 q-axis ACR Output
ACR output of (q-axis) Monitors the current
control output value for the motor secondary
current (Iq).
10 V: 100%
0.1
%
− A − 5F
U6-08 d-Axis ACR Output
ACR output of (d-axis) Monitors the current
control output value for the motor excitation
current (Id).
10 V: 100%
0.1
%
− A − 60
No. Name Description Range Def.
Control
Mode
Addr.
Hex
V/
f
O
L
V
P
M

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
