A.3 Common Drive Specifications
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 323
Specifications
A
Service Conditions
Altitude ~
1000 m and below
(output derating of 1% per 100 m above 1000
m)
Ambient Operating
Temperature
Degrees C
-10~+40º C (NEMA Type 1)
-10~+50º C (Open-Chassis)
Derating:
NEMA Type 1 +50º C /
Open-Chassis +60º C, 80% derate
NEMA Type 1 +60º C 60% derate
Enclosure Types
Location Indoor free from corrosive gases or dust
IP20 Standard
NEMA Type 1 Standard
Humidity %RH 95% RH or less, non-condensing
Oil Tolerance ~ Option
Fire Resistance ~ UL508C
Hazardous Materials ~ RoHS compliant
Input Voltage Specifications ~
Single-Phase 200~240 V 50/60 Hz
Three-Phase 200~240 V 50/60 Hz
Three-Phase 380~480 V 50/60 Hz
-15%, +10%
Input Noise Tolerance ~
Impulse noise, switching noise according to
(VES-J5002)
Input Frequency ~ 50/60 Hz, +/-5%
Electromagnetic Immunity ~
Standard: EN61800-3 second environment
(motor length 5 m)
Leakage Current ~
1 mA and less, when ground capacitor switch
is off
DC Input ~
Compatible, all models:
200V class models: Input range 270~340 V
400V class models: Input range 510~680 V
Displacement Power Factor ~ 0.98
Drive Efficiency % 96 to 98
Safety
Insulation Voltage Resistance
200V Models: 2000V, 1 minute (Main Circuit
Control: 2600 V, 5 s)
400 V Models: 2500 V, 1 minute
(2600 V, 5 s)
Smoke/Fire Production Non-smoke producing material
Heat Generation
Enclosure Exhaust Temperature 65º C,
Maximum 80 º C or less
Discharge Time 5 minutes maximum
Safety Standards.
Standard
(IEC61508 SIL2, EN954-1 category 3)
Stop Cat.0 (Hardwire BB): standard
Fast-stop Yes
Item Specification
