YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 405
Parameter List
B
r1-04
DWEZ Connection
Parameter 2 (lower)
Parameter 2 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 1843 —
r1-05
DWEZ Connection
Parameter 3 (upper)
Parameter 3 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 1844 —
r1-06
DWEZ Connection
Parameter 3 (lower)
Parameter 3 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 1845 —
r1-07
DWEZ Connection
Parameter 4 (upper)
Parameter 4 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 1846 —
r1-08
DWEZ Connection
Parameter 4 (lower)
Parameter 4 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 1847 —
r1-09
DWEZ Connection
Parameter 5 (upper)
Parameter 5 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 1848 —
r1-10
DWEZ Connection
Parameter 5 (lower)
Parameter 5 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 1849 —
r1-11
DWEZ Connection
Parameter 6 (upper)
Parameter 6 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 184A —
r1-12
DWEZ Connection
Parameter 6 (lower)
Parameter 6 for connecting DWEZ (lower).
0 to
FFFFH
0–AA
184B
H
—
r1-13
DWEZ Connection
Parameter 7 (upper)
Parameter 7 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 184C —
r1-14
DWEZ Connection
Parameter 7 (lower)
Parameter 7 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 184D —
r1-15
DWEZ Connection
Parameter 8 (upper)
Parameter 8 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 184E —
r1-16
DWEZ Connection
Parameter 8 (lower)
Parameter 8 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 184F —
r1-17
DWEZ Connection
Parameter 9 (upper)
Parameter 9 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 1850 —
r1-18
DWEZ Connection
Parameter 9 (lower)
Parameter 9 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 1851 —
r1-19
DWEZ Connection
Parameter 10 (upper)
Parameter 10 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 1852 —
r1-20
DWEZ Connection
Parameter 10 (lower)
Parameter 10 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 1853 —
r1-21
DWEZ Connection
Parameter 11 (upper)
Parameter 11 for connecting DWEZ (upper).
0 to
FFFFH
0 – A A 1854 —
r1-22
DWEZ Connection
Parameter 11 (lower)
Parameter 11 for connecting DWEZ (lower).
0 to
FFFFH
0 – A A 1855 —
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
