D.3 UL Standards
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 447
Standards Compliance
D
Disable the electronic overload protection (L1-01 = 0: Disabled) and wire each
motor with its own motor thermal overload when connecting the drive to more than
one motor for simultaneous operation.
Enable the motor overload protection (L1-01 = “1”, “2”, or “3”) when connecting
the drive to a single motor unless there is another means of preventing motor
thermal overload. The electronic thermal overload function causes an OL1 fault,
which shuts off the output of the drive and prevents additional overheating of the
motor. The motor temperature is continually calculated as long as the drive is
powered up.
Setting L1-01 = 1 selects a motor with limited cooling capability below rated (base)
speed when running at 100% load. The OL1 function derates the motor when it is
running below base speed.
Setting L1-01 = 2 selects a motor capable of cooling itself over a 10:1 speed range
when running at 100% load. The OL1 function derates the motor when it is running
at 1/10 or less of its rated speed.
Setting L1-01 = 3 selects a motor capable of cooling itself at any speed —
including zero speed — when running at 100% load. The OL1 function does not
derate the motor at any speed.
Setting L1-01 = 4 selects protection for a PM motor.

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
