YASKAWA V1000 Series Installation & Start-Up Manual

3.1 Section Safety
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 55
Electrical Installation
3
• Do not use unshielded cable for control wiring.
Failure to comply may cause electrical interference resulting in
poor system performance. Use shielded, twisted-pair wires and
ground the shield to the ground terminal of the drive.
• Do not allow unqualified personnel to use the product.
Failure to comply could result in damage to the drive or braking
circuit.
Carefully review instruction manual TOBPC72060000 when
connecting a braking option to the drive.
• Do not modify the drive circuitry.
Failure to comply could result in damage to the drive and will void
warranty.
Yaskawa is not responsible for any modification of the product
made by the user. This product must not be modified.
• Check all the wiring to ensure that all connections are correct
after installing the drive and connecting any other devices.
Failure to comply could result in damage to the drive.
NOTICE

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
