Equipment and Port Configuration SFP Pluggable Modules
5. Assign the SFP the same VLAN as the MGMT VLAN on the ML NE. To continue SFP
PWE Service configuration, refer to MiTOP-E3/T3 User Manual or to brief checklist
table provided in MiTOP Configuration Table.
MiTOP Configuration Example
MiTOP Configuration Example
1. Install a MiTOP device in ML SFP socket.
2. Configure Management access to the MiTOP device (either via MAV or via
Dongle SFP Configuration Adaptor):
Add Tagged port of SFP to MGMT VLAN of the ML;
Define IP address, IP mask and default gateway IP address of the MiTOP (via MAV
it is on SFP module pane). For example:
o MiTOP-1: 10.1.50.1, 255.255.0.0, 10.1.0.100
o MiTOP-2: 10.1.50.2,255.255.0.0, 10.1.0.100
3. Access MiTOP-1 via Browser (10.1.50.1):
User: su
Password 1234
4. Enter MiTOP Physical Port Configuration (Configuration > Physical Ports):
Set E3 or T3
Enter E3/T3
Set Tx Clock Source: CO - LBT (on CPE - Adaptive)
Set needed Line code and Line type
Save parameters
Attention! Save must be performed after changing of each parameter, however a Save
button is not available in each page. In such pages, click the Previous Menu and save
your changes.
5. In Configuration (Applications/Multiservice over PSN) of MiTOP-1, access PW
and General Parameters, define the following and then Save:
Set Source IP (for MiTOP-1 - 10.1.50.1)
PSN Type UDP/IP or MEF
6. In Configuration (Applications/Multiservice over PSN) of MiTOP-1, access Peer,
define the following, Save and then check that a Peer MAC address appeared:
Peer Name 2 (in MiTOP-2 it will be Peer Name 1)
Peer IP address - 10.1.50.2 - address of MiTOP-2
Optionally set MAC (usually discovered automatically by ARP)
Attention! If you need to edit any parameter, you must fill all parameters in a table,
because clicking the Save copies values from the table.
